Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width

Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width
Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width

Large Image :  Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width

Product Details:
Place of Origin: China
Model Number: EL-PCTM
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Packaging Details: Wooden Case
Delivery Time: 2-3 weeks
Payment Terms: T/T

Parallel / Flat Cable Tape Wrapping Machine 10-45mm Width

Description
Tape Length: 50mm Applicable Cable Diameter/Width: ≤8mm
Applicable Cable Length: ≥140mm Width: 10mm--45mm
Power Supply: 220V And 110V Dimensions: L*W*H 300*250*500mm
High Light:

Parallel cable Tape Wrapping Machine

,

w45mm Tape Wrapping Machine

,

w45mm flat cable taping machine

Parallel Cable Flat Cable Taping Machine with Digital Adjustable Tape Length



This semi-automatic wire harness tape wrapping system is designed specifically for taping flat cables. It can also be used to wrap cables around.



  • Designed for flat wire and ribbon cable taping.
  • After crimping, it is suitable for medium taping.
  • Tape length can be adjusted digitally, and it is simple to use.
  • Stable and effective, lowering operation intensity and reducing labor costs
  • The taping effect is more tight and flattering.



For more information, please contact our sales people. We will be very happy to access your needs and give you back a best solution for your case. Our company also be very good at doing modifications for all of our machines to suit your particularly needs. Make-to-Your-Need is one of our key services. You will find that we are not only a machinery maker but also a total solution provider to your practically cases. We are looking forward to have investigation and discussion with you.



Tape length 50mm
Applicable cable Diameter/Width ≤8mm
Applicable cable Length ≥140mm
Width 10mm--45mm
Power supply 220V and 110V
Power 200W
Weight 45kg
Dimensions L*W*H 300*250*500mm
Production Rate 20 pcs/ min
